Nested patterns - offcuts



How offcut sizes are dealt with for nested patterns



Nested patterns can contain offcuts and follow the parameters for offcuts.






Offcuts with duplicate sizes are not aggregated for nested patterns.



When a nested pattern is transferred to the machining centre the offcuts are converted into 1 or 2 rout contours depending on if they are along a whole side or just on a corner.
